| AC Rated Output Power (kW) | 8-10 |
| AC Overload capacity | 120% (Long-term), 160% (Instantaneous 10s) |
| Max PV. input power (kW) | 15 |
| European Efficiency | 97% |
| Energy Capacity | 5.12 kWh |
| Operating Temperature Range | -25°C ~ 60°C (With heating function) |
| Battery Type | LFP (32S1P) |
| Scalability | Supports up to 36 modules (6 PCS in parallel; each PCS + BCU controls 6 batteries, 6x6=36; a single PCS can control a maximum of 6 batteries / 30kWh |
| Rated voltage | 102.4 |
| Protection Rating | IP65 |
